| Brand Name: | Hailos |
| MOQ: | 1 |
| Price: | $3000~$9000 |
| Delivery Time: | 5-8 weeks |
| Payment Terms: | T/T |
This water cooled industrial chiller adopts high-efficient shell & tube condenser to realize efficient heat dissipation and stable operation. Equipped with intelligent microprocessor control system, it achieves precise chilled water temperature regulation to meet strict industrial cooling demands. Compact structure with reliable compressor ensures long service life, widely applied in injection molding, electroplating, chemical, pharmaceutical and mechanical processing industries. Optional Modbus communication supports remote monitoring and centralized management.
| Parameter | Model | HLS-20W | HLS-25W | HLS-30W | HLS-36W | HLS-40W | HLS-45W | HLS-50W | HLS-60W |
| Cooling capacity | KW 50HZ/60HZ |
67.14 78.56 |
81.53 95.39 |
99.91 116.05 |
118.8 140.5 |
129.06 151.00 |
148.5 175.2 |
165195 | 196230 |
Running current |
A | 42.1 | 48.5 | 58.3 | 64 | 75.4 | 82.3 | 90.5 | 110 |
| Power Supply | Volt | 3P-380/415V-50/60HZ | |||||||
| Refrigerant | Name | R22 | |||||||
| Fill (kg) |
2.8*4 | 6.3*2 | 5.6*3 | 7.2*3 | 5.6*4 | 9*3 | 7.5*4 | 7.2*5 | |
| Control Method | Thermal expansion valve | ||||||||
| Compressor | Type | Hermetic scroll | |||||||
| Power (KW) |
3.75*4 | 9.4*2 | 7.5*3 | 9*3 | 7.5*4 | 11.25*3 | 9.37*4 | 9*5 | |
| Cooling water |
water flow m³/h |
14.44 | 17.54 | 21.32 | 24.12 | 27.74 | 30.15 | 33.5 | 40.2 |
| Pipe diameter | 2" | 2-1/2" | 2-1/2" | 2-1/2" | 3" | 3" | 3" | 3" | |
| Chilled Water | water flow m³/h |
11.55 | 14.03 | 17.06 | 19.5 | 22.19 | 24.75 | 27.5 | 33 |
| water tank (L) |
80 | 80 | 100 | 200 | 200 | 250 | 400 | 500 | |
| Pipe diameter | 2" | 2-1/2" | 2-1/2" | 2-1/2" | 3" | 3" | 3" | 3" | |
| Waterpump | Power (KW) |
2.2 | 2.2 | 3 | 3.75 | 3.75 | 3.75 | 3.75 | 3.75 |
| Pressure(Mpa) | 0.23 | 0.23 | 0.23 | 0.23 | 0.23 | 0.23 | 0.23 | 0.23 | |
| Dimension | Length (mm) |
2080 | 2080 | 2080 | 2180 | 2180 | 2180 | 2080 | 2180 |
| Width (mm) |
800 | 830 | 8300 | 8800 | 880 | 880 | 1550 | 1550 | |
| Height (mm) |
1460 | 1460 | 1500 | 1500 | 1500 | 1600 | 1460 | 1460 | |
| Weight | kg |
440 |
620 |
690 |
740 |
850 |
1100 |
1450 |
1880 |
